provided by gisewhcs from the Hififorum

——————————————————————————————————————————-

provided by Fabian aus dem Epicenter-Forum

Rated power measured according to DIN 45500 up to 1% distortion factor in 13,5V

Audio System ADS 12002

1 × 142 watts, channel 1 at 4 Ohm
2 × 130 watts, channel 1 + 2 at 4 Ohm
Current consumption 29,3A
efficiency 65,7%

1 × 404 watts, channel 1 + 2 bridged at 4 Ohm
Current consumption 52,6A
efficiency 56,9%

404 watts total power
