Rated power measured according to DIN 45500 up to 1% distortion factor in 13,5V

µ-Dimension ProX2K.1D

1 × 756 watts, channel 1 at 4 Ohm with 13,4V supply voltage
Current consumption 67,2A
efficiency 84%

1 × 1301 watts, channel 1 at 2 Ohm with 13,3V supply voltage
Current consumption 120A
efficiency 81,5%

1 × 1696 watts, channel 1 at 1,33 Ohm with 13,2V supply voltage
Current consumption 163A
efficiency 78,8%

1 × 2025 watts, channel 1 at 1 Ohm with 13,1V supply voltage
Current consumption 200A
efficiency 77,3%

2025 watts total power

measured up to the clipping limit at 100 Hz because of fixed preset low-pass filter
